BLP Series

LED Backlit Panel

Typically used to replace traditional fluorescent lights lay-in fixture. The BLP series is a next generation family of edge lit led flat panel fixtures designed to lay in drop ceilings in offices, schools, and healthcare applications. The flat panels are fully dimmable, compatible with building controls, motion sensors, and daylight harvesting systems. The design of the BLP series panels produces an even and consistent shadow-less light. The LED’s enable long life, high lumen maintenance, high CRI, low maintenance, and constructed without hazardous materials.
Specification Sheet

Resources

  • Built to UL 1598 and 2108 standards, and bear appropriate ETL labels.
  • Damp location labeling is standard.
  • Long-Life LED’s 60,000 hours at L80 with projected life over 100,000 hours for reduced maintenance
  • Optional On/Off or Bi-Level Motion sensor
  • 0-10V continuous dimming driver

CCT

  • 3500K
  • 4000K
  • 5000K

CRI

  • 80 CRI

Color / Finish

  • White

Controls Options

  • Motion Sensor

Dimming Protocol

  • 0-10 V

Lamp Life

  • 50000 hrs
  • 72000 hrs
  • 100000 hrs

Lamp Source

  • Fluorescent
  • LED

Listings

  • ETL

Lumens

  • 4400 Lm
  • 5500 Lm

Materials

  • Aluminum

Mounting

  • Ceiling
  • Recessed
  • Surface
  • Wall

Ratings & Compliance

  • Damp
  • Dry
  • IC
  • LM80
  • TM21

Voltage

  • 120-277 V

Warranty

  • 5 yr

Watts

  • 40 w
  • 50 w
